| Net Weight | 0.340kg |
| Packing List | 1N Router, 1N Power Cable, 1N CAT6 Network Cable, 1N Quick Start Guide |
| Packing Method | Single pack |
| Working Temperature | -20⁰ C to 70⁰ C |
| Storage Temperature | -40⁰ C to 85⁰ C |
| Working Humidity | 10% to 90% RH non-condensing |
| Installation Mode | Table-Top |
| Wi-Fi | 2.4GHz: IEEE 802.11 b/g/n WiFi 210.7Mbps@TX and 190.4Mbps@RX with 20/40MHz bandwidth |
| Wireless Standard | IEEE 802.11b/g/n @2.4GHz |
| Working Frequency Band | 2.4 GHz |
| Wireless Range | 100 Mtr Radial |
| Max. Connections | 8 |
| Transmitting Power | LTE: +23_+ 2dBm |
| Bandwidth | ＜20/40 MHz (2.4GHz) bandwidth |
| Wireless Features | Single Band Supported,MU-MIMO Supported |
| Antenna | 3 Inbuilt Antennas |
| Battery Backup | Up-To 3 Hours* |
| LED Indicator | Red Led;- Power, Blue Led;- Internet |
| LED Description | Red Blink ;- Wireless user Connected, Blue blink ;- Network Searching |
| Button | Power Switch Button, Reset Button |
| SIM Slot | Dual NANO SIM Auto Switching mode |
| Battery Type | Lithium-ion battery 4500mAh |
| RAM & ROM | 64MB |
| LAN Port | CAT5 Ethernet |
| Network Band | FDD : B1/B3/B5/B8 ; TDD : B40/B41 Oversea Operator Band Customised |
| Power Supply Method | Power Supply Adapter |
| Power Rating | DC 5V2A / 12V1A |
| Power Input | C-Type |
| Max. Power Consumption | 12≤W |
| Operating Mode | Wireless Mode |
| Router Default IP | 192.168.150.1 |
| Login Interface ID | User Name: - admin Password: - admin |
| Default SSID/WIFI Name | COFEXXXX (Can be Modified) |
| Default SSID Password | 12345678 (Can be Modified) |
| Internet Access method | 3 Way Ctype With Power / Ethernet / Wireless |
| DHCP | DHCP Client List DHCP Server |
| Parental Control | Speed Limit, Internet Access Period, Filter URL, Custom Profiles |
| IP Version | IPv4, IPv6, Support fast and secure WPS connection Support hiding wireless network name |
| Security Mechanism | Support Firewalls, Login Authentication |
| Firewall | Port Mapping; Port forwarding; Port filtering; URL filtering; UPNP; DMZ |
| Security Mode | WPA2-PSK,WPA/WPA2-PSK Supported |
| Management Method | Web UI |
